3 Seat Belt
Parameter: Value
Webbing material: Polyester
Width: 46mm ±1mm
Thickness: 1.2mm
Static break strength: ≥28.3kN
Product Introduction
The Most Popular Choice for Cars
Three-point seat belts are the main safety device in passenger cars. They give good protection and comfort. Our 3 seat belt also have an ELR lock and a load limiter. We have made 3 seat belt for nearly 30 years. They are our core product.
Strong Webbing and Smart Locking
The webbing is high quality polyester. Width is 46mm ±1mm, thickness 1.2mm. Static break strength is ≥28.3kN. That is far above the national 14.7kN rule. The retractor is an ELR type. It moves freely during normal driving. In a sudden stop or crash, it locks at once. The lock sensitivity is set to 0.45g. It does not lock too early or too late. This three-point seat belt also has a 4kN–6kN load limiter. After locking, it releases a little webbing to soften chest force. This helps prevent rib injury.
Safe Materials and Global Certificates
The fire rating is GB 8410-2006 A-0. Oxygen index is 25%. The product follows both GB 14166 and ECE R16 rules. It has 3C and E-MARK certificates. Our lab tests every batch for pull force, locking, durability, and fire resistance. We supply Chery, FAW, and Foton. These 3 seat belt fit sedans, SUVs, vans, and buses. They are a standard safety choice for driver, front passenger, and rear seats.
Data Table – Three-Point Seat Belts
|
Parameter |
Value |
|
Webbing material |
Polyester |
|
Width |
46mm ±1mm |
|
Thickness |
1.2mm |
|
Static break strength |
≥28.3kN |
|
ELR lock sensitivity |
0.45g |
|
Load limiter range |
4kN – 6kN |
|
Flame retardant class |
GB 8410-2006 A-0 |
|
Oxygen index |
25% |
|
Certifications |
3C, E-MARK, GB 14166, ECE R16 |
